Модуль коммутатора HP ProCurve 10/100/1000 Module P/N: JE084A

P/N: JE084A Производитель: HP Наличие: 15-20 дней Гарантия ВсемКомп: звоните Состояние: NEW or REF Цена: Запросить цену

Ports	92 RJ-45 autosensing 10/100/1000 PoE+ ports(IEEE 802.3 Type 10BASE-T, IEEE 802.3u Type 100BASE-TX, IEEE 802.3ab Type 1000BASE-T, IEEE 802.3at PoE+), Media Type: Auto-MDIX, Duplex: 10BASE-T/100BASE-TX: half or full; 1000BASE-T: full only; 2 SFP+ 10-GbE ports, Duplex: full only; 8 open module slots; Supports a maximum of 288 autosensing 10/100/1000 ports or 96 10-GbE ports or 288 mini-GBICs, or a combination
Mounting	Mounts in an EIA-standard 19 in telco rack or equipment cabinet (hardware included); horizontal surface mounting only. Optional 4-post cabinet rail is available (see switch 8212zl ordering guide).
Memory and processor	Gigabit Module : ARM9 @ 200 MHz, packet buffer size: 144 Mb QDR SDRAM; 10G Module : ARM9 @ 200 MHz, packet buffer size: 36 Mb QDR SDRAM; Management Module : Freescale PowerPC 8540 @ 666 MHz, 4 MB flash, 128 MB compact flash, 256 MB DDR SDRAM
Latency	1000 Mb Latency: < 3.7 µs (FIFO 64-byte packets); 10 Gbps Latency: < 2.1 µs (FIFO 64-byte packets)
Throughput	up to 739 million pps
Routing/switching capacity	993.6 Gbps
Switch fabric speed	1.1 Tbps
Routing table size	10000 entries
Management features	HP PCM+; HP PCM (included); command-line interface; Web browser; configuration menu; out-of-band management (serial RS-232C)

Power and operating requirements

Input voltage	100-127/200-240 VAC
Input frequency	50/60 Hz
Safety	CSA 22.2 No. 60950; UL 60950; IEC 60950; EN 60950; IEC 60825
Electromagnetic compatibility	FCC Class A; FCC part 15 Class A; ICE-003, Canadian Radio Interface Regulation; VCCI Class A; EN 55022/CISPR 22 Class A
Operating temperature range	0 to 45°C
Operating humidity range	15 to 95% @ 131°F (55°C) (noncondensing)

Dimensions and weight

Dimensions (W x D x H)	47.5 x 44.45 x 39.62 cm
Weight	46.61 kg

What's included

Warranty	Lifetime, advance replacement, next business day
